XLD-VGA 32X32 matrix host
Product overview
· Adopts 500M high-bandwidth chip with long-term line drive function;
· The first to support 2048X1536 high-resolution design circuit
· Adopt long-distance signal transmission distortion gain compensation technology;
· Using Digital Synchronous Identification Processing (DSIP) technology
· Built-in cycle switching function, the interval time and channel can be set arbitrarily
· Built-in 32 sets of scene storage functions, which can be operated directly on the panel
· Using programmable logic array circuit (CPLD), the performance is more stable;
· 32-channel VGA computer signal input; 32-channel VGA computer signal output;
· 32-channel VGA computer audio output; 32-channel VGA computer audio output; (optional)
· Computer video input and output terminals adopt HD15PIN (VGA) interface;
· Compatible with the codes and instructions of all similar products on the market;
· Dedicated port, can be directly connected to Xinlaida wireless touch screen, plug and play;
· Unique TCP/IP network control and management function, can be controlled through Ethernet; (optional)
· Full chip SMD process, unique ESD electrostatic protection function;
· Xinlaida series VGA computer video switcher is a high-performance intelligent matrix switching device specially designed for display switching of computer signals. It is used to switch any computer video output channel to any channel. This series of products is widely used in large-screen projection display projects, audio-visual teaching, command and control centers, multimedia conference rooms and other occasions;
· This product is an intelligent device with high reliability. It adopts fault-tolerant technology in the design and adopts a communication interface circuit with high anti-interference ability to ensure the reliability of communication. It has infrared remote control function and RS232 communication function. Users can conveniently complete signal switching during the demonstration process;
· This product has on-site switching memory protection when power is off, and has an RS232 communication interface, which can be easily used with computers, remote control systems or various remote control devices (such as Xinlaida and other control systems);
· Global wide voltage design, adaptable to AC 100~240V, 50/60Hz;
· High quality, mass production, high compatibility and stability, and high cost performance;
|
Category |
|
|
VGAVideo |
|
|
Gain |
0 dB |
|
Bandwidth |
500MHz (-3dB),Full load |
|
Multi-channel to one-channel crosstalk and |
-60dB @10 MHz, -39dB @100 MHz |
|
Switching speed |
200 ns(Maximum time) |
|
Signal type |
RGBHV, RGBS, RGsB, RsGsBs, High Definition TV (HDTV), component video, S-video, composite video (signal) |
|
VGAVideo input |
|
|
Interface |
15-pin HD Female interface |
|
Minimum/Maximum level |
Analog signal: 0.5V ~ 2.0V p-p |
|
Impedance |
75 Ω |
|
Return loss |
-30dB@5MHz |
|
Signal Strength |
1V p-p ： YIngredients video, S-video, composite video; 0.7V p-p: VGA(computer signal);0.3V p-p: R-Y and B-YIngredient video, S-video |
|
Maximum DC offset error |
15mV |
|
Horizontal frequency response |
15 kHz ~ 145 kHz |
|
VGAVideo output |
|
|
Interface |
15-pin HD Female interface |
|
Minimum/Maximum level |
0.5V ~ 2.0V p-p |
|
Impedance |
75 Ω |
|
Return loss |
-30dB@5MHz |
|
DC compensation |
±5mV |
|
Synchronization signal |
|
|
Input/Output type |
RGBHV, RGBS, RGsB, RsGsBs,Composite video,Ingredients Video |
|
Input level |
0.5V- 5.0V p-p,: 4.0V p-p Normal |
|
Output level |
AGC-TTL: 5Vp-p, unterminated |
|
Input impedance |
510 Ω |
|
Output impedance |
75 Ω |
|
Maximum rise/Falling time |
4ns |
|
Maximum transmission delay |
Horizontal:90ns Vertical:160ns |
|
Video format |
NTSC 3.58NTSC 4.43NTSC 4.43PAL, SECAM |
|
Polar |
Positive or negative (exactly the same as the input) |
|
RS-232Control interface |
|
|
Serial control interface |
RS-232, 9-Needle mother DType interface |
|
Baud rate and protocol |
Baud rate: 9600, Data bits: 8Bit, Stop bit: 1, No parity bit |
|
Serial control port structure |
2 = TX, 3 = RX, 5 = GND |
|
Specifications |
|
|
Power supply |
100VAC ～ 240VAC, 50/60 Hz, International adaptive power supply |
|
Temperature |
Storage and use temperature: -20°～ +70°C |
|
Humidity |
Storage and use humidity:10% ～ 90% |
|
Mean time between failures |
60,000 hours |
|
Warranty |
1Year free warranty,Lifetime maintenance |
|
