200W network mini dome XLD-IR401NW-200H

Product model：XLD-IR401NW-200H Views：3 2026-08-16

Product overview

1. Adopt high-performance 2 million pixels 1/3" CMOS; 2. Support dual stream compression technology; 3. Horizontal 360° rotation, driven by precision stepper motor, running smoothly and positioning accurately; 4...

Get a solution quote 18922896702

1. Using high-performance 2 million pixels 1/3" CMOS;
2. Support dual stream compression technology;
3. Horizontal 360° rotation, driven by precision stepper motor, running smoothly and positioning accurately;
4. The rotation speed is automatically adjusted according to the lens zoom factor, automatic focus, and automatic white balance;
5. Built-in full-screen OSD screen menu. Compatible with multiple control protocols and adjustable baud rate;
6. Vertical 90°, automatically flip 180° and then monitor continuously.
7. Equipped with 6 high-performance dot matrix infrared lights, with a night vision infrared distance of 80 meters;
8. Full metal shell, stronger heat dissipation function.

Model number	XLD-IR401NW-200H
Imaging source	1/3" CMOS
Signal mode	PAL/NTSC
Clarity	1080P
Effective pixels	1920 (horizontal) ⅹ1080 (vertical)
Minimum illumination	Color to black and white, color: 0.01Lux, black and white: 0.001Lux
Signal-to-noise ratio	>60dB (enhanced)
Backlight compensation	On/Off
White Balance	Auto
Electronic shutter	PAL:1/25~1/100000 seconds NTSC:1/30~1/100000 seconds
Focal length	5~50mm
Optical zoom	10 times
Focus	Auto/manual, using high-performance DSP to achieve fully digital ultra-high-speed continuous focusing function
Preset	255
Pattern Scan	4 entries, each can record 200 actions
Cruise track	30 preset points can participate in the cruise, and the stay time at the preset points can be set
Other scans	Supports horizontal scanning, two-point area scanning, and random scanning
Rotation range	Unlimited 360° horizontally, 90° vertically, automatic flip
Rotation speed	Horizontal and vertical: minimum 0.01 degrees, maximum 200 degrees/second
Communication	RS-485, PELCO D and PELCO P
Video encoding	H.264 Main Profile encoding; MJPEG/JPEG Baseline encoding
Audio encoding	G.711, G.726
Image main stream	1920*1080,25 frames/second
Image sub-code stream	D1, VGA, 640360, 568320, CIF, QVGA, 320*192
Video compression bit rate	32Kbps-16Mbps continuously adjustable, supports CBR/VBR
Protocol support	TCP/IP, UDP, RTP, RTSP, RTCP, HTTP, DNS, DDNS, DHCP, FTP, NTP, PPPOE, SMTP, UPNP
ONVIF protocol	Support
Infrared distance	80 meters
Protection level	IP66
Power supply	DC12V/3A
Working environment	-20℃～+50℃ (optional temperature control component), <95%RH
