●The high-definition digital matrix XLD-6HD12 series is a product specially produced for the front-end equipment, all of which are 200W (1920*1080P) high-definition network video stream input, and the central 12-screen TV wall. It is used to complete the functions of decoding 200W (1920*1080P) high-definition video onto the TV wall, loop switching, streaming media forwarding and other functions.

Special instructions:
●A single machine has a maximum of 12 VGA/DVI/HDMI outputs, supporting 12 (12*1)/24 (12*2) 200W (1920*1080P) high-definition videos on the TV wall.
●Supports all resolutions 200W (1920*1080) and below, 1024P (1280*1024), 720P (1280*720), WD1 (960*576), D1 (704*576), CIF (352*288) video decoding and display
●Support HDMI, DVI, VGA simultaneous output, the output resolution can reach up to 1920x1080P, and the images of different channels can be previewed separately
●A single screen can be customized to display 1/2/4, and 12 screens can be split into 1/2/4 at the same time
●All channel videos on 12 screens support main stream (1920*1080P) display
●Audio and video output simultaneously, supporting two-way voice
●Supports synchronous switching, group switching, cycle switching, and manual switching
●Compatible with encoding equipment from more than 20 manufacturers including Onvif protocol, Xinlaida, Haikang, Dahua, Hanbang, Hengyi, Dali, Tiandi Weiye, Huanghe, Lanchi, Yiwei, Uniview, Infineon, Jiego, Jingyang, Tianshitong, Xiongmai, German MOBOTIX, Epstar, Axis, etc.
●A single 12-screen 200W (1920*1080P) high-definition digital matrix device supports simultaneous decoding of equipment from multiple manufacturers and onto the TV wall
●Single HD matrix streaming media forwarding supports 128 client access at the same time
●Multiple 12-screen 200W (1920*1080P) high-definition digital matrices are seamlessly cascaded, and any video can be switched to any channel on the TV wall
●Supports Internet, VPN, LAN, 3G, Wireless, ADSL, fiber optic
●Supports network alarm host (Congwen Alarm Reception Center, Honeywell, Nanjing Inant, Bosch), access control equipment (Weigeng, Kingnord), intercom (Laibang, Shibang), and patrol linkage video output
●Support multi-level vector electronic map linkage alarm video output, support GIS electronic map
●Unique control center with one machine and three screens (preview center, digital matrix, vector electronic map) operation
●Full Chinese interface three-dimensional main control keyboard
