●The high-definition digital matrix XLD-6H9 series is a product specially produced for the front-end equipment, all of which are 100W (1280*720P) high-definition network video stream input, and the central 9-screen TV wall. It is used to complete the functions of decoding 100W (1280*720P) high-definition video onto the TV wall, loop switching, streaming media forwarding and other functions.

Special instructions:
●A single machine has a maximum of 9 VGA/DVI/HDMI outputs, supporting 9 (9*1)/36 (9*4) 100W (1280*720P) high-definition videos on the TV wall.
●Supports WD1 (960*576), D1 (704*576), CIF (352*288) video decoding and display of all resolutions 100W (1280*720) and below
●Support HDMI, DVI, VGA simultaneous output, the output resolution can reach up to 1920x1080P, and the images of different channels can be previewed separately
●A single screen can be customized to display 1/2/4, and 9 screens can be split into 1/2/4 at the same time
●All channel videos on 9 screens support main stream (1280*720P) display
●Audio and video output simultaneously, supporting two-way voice
●Supports synchronous switching, group switching, cycle switching, and manual switching
●Compatible with encoding equipment from more than 20 manufacturers including Onvif protocol, Xinlaida, Haikang, Dahua, Hanbang, Hengyi, Dali, Tiandi Weiye, Huanghe, Lanchi, Yiwei, Uniview, Infineon, Jiego, Jingyang, Tianshitong, Xiongmai, German MOBOTIX, Epstar, Axis, etc.
●Single 9-screen 100W (1280*720P) high-definition digital matrix equipment supports simultaneous decoding of equipment from multiple manufacturers and onto the TV wall
●Single HD matrix streaming media forwarding supports 128 client access at the same time
●Multiple 9-screen 100W (1280*720P) high-definition digital matrices are seamlessly cascaded, and any video can be switched to any channel on the TV wall
●Supports Internet, VPN, LAN, 3G, Wireless, ADSL, fiber optic
●Supports network alarm host (Congwen Alarm Reception Center, Honeywell, Nanjing Inant, Bosch), access control equipment (Weigeng, Kingnord), intercom (Laibang, Shibang), and patrol linkage video output
●Support multi-level vector electronic map linkage alarm video output, support GIS electronic map
●Unique control center with one machine and three screens (preview center, digital matrix, vector electronic map) operation
●Full Chinese interface three-dimensional main control keyboard
